Quantum Series High Static Pressure Duct Air Conditioner

The Midea Quantum Series High Static Pressure Duct system is a powerful and flexible commercial air conditioning solution designed for demanding environments. Engineered for consistent airflow and superior performance, this system is ideal for offices, retail spaces, restaurants, showrooms and light industrial applications.

With advanced DC inverter technology, intelligent airflow control and high-efficiency filtration options, the Quantum Series ensures optimal comfort, improved indoor air quality and energy-efficient operation. Its compact design, long piping capability and flexible installation make it a reliable choice for modern building requirements.

• High static pressure performance for effective airflow in complex duct systems
• Consistent air volume control for reliable, long-term operation
• Energy-efficient full DC inverter technology with reduced noise levels
• Flexible installation with extended piping and layout adaptability
• Compact design for easier transport and installation in tight spaces
• Optional advanced filtration (F7 / H13 HEPA) for improved indoor air quality
• Intelligent filter monitoring for proactive maintenance
• Built-in high-lift drain pump for efficient condensate management
• Quiet operation for enhanced occupant comfort
• Smart control compatibility with centralised and BMS systems
• Intelligent fault and leak detection for improved system reliability
• Cooling capacity: 20 kW – 56 kW
• Heating capacity: 23.5 kW – 63 kW
• Airflow rate: Up to 8,400 m³/h (model dependent)
• External static pressure: Up to 400 Pa (adjustable)
• Indoor unit power supply: 220–240V / 1 Phase / 50–60Hz
• Outdoor unit power supply: 380–415V / 3 Phase / 50–60Hz
• Sound pressure level: 37 – 59 dB(A) (model dependent)
• Refrigerant type: R410A
• System type: Heat pump
• Indoor unit configuration: Single indoor unit connection

Warranty: 5 Years on Unit and 5 Years on Compressor
